Heavy cutting with high load, fixed-angle index rotary table
With dual gear transmission design, it features heavy load capacity and auto rotation to 4 angles. (0, 90, 180, 270 degree).Clamping force can be assured by strong hydraulic system. Accuracy and stability can also be assured during heavy cutting.Besides, it can bear work piece eccentric load on the range of 200mm outside outer dia. 200mm. It has accuracy performance of excellent workpiece eccentric load.
2019-10-08
-
Horizontal machining with manual rotary table
The Ganro GCT Series of manual horizontal index tables is easy to operate and extremely rigid with a two piece Hirth coupling design. It is available in a range of table sizes from 300mm (11.81") to 1400mm (55.12").
2019-10-04
-
Fine cutting for brittle ceramic grinding wheel with rotary table
Try to enter the processing market by studying ceramics CBN grinding wheel about how to be machined and forming.
A grinding wheel is a wheel composed of an abrasive compound (materials including Ceramics, SIC and diamond) consisting of coarse-particle aggregate pressed and bonded together by a cementing matrix to form a solid, circular shape.
The manufacturing method of grinding wheels is by mixing the ingredients, molding, pressing, firing, refining and inspection.
After firing process, grinding wheel must be machined to exact size by machine tool.Since ceramics are hard and brittle material, it’s a challenge for cutting.
Each manufacturing process could be a challenge by concertizing varieties of scientific concept and combing finished product together.2019-09-30
-
Very heavy load test on rotary table
Please take a look at our most popular models of HP/HR Horizontal series and you will realize that we conduct the extremely heavy load test on the table by the severe methods in order to give full play to the feature of heavy load rotary table.
2019-09-29
-
Very heavy load test on rotary table
Based on the art of science and engineering, the procedure is very complicated and time-consuming from design till put into production line
It is not only the test of persistence, but also the mind. Especially using on producing machine tools, it involves in mechanics, physics and mechanic design.
Every stage has its difficulty and challenge to make true the initial concept and assembly all the materials and parts to be a finished product.
It just like brigade relay, every role is essential part of the team from order taken to product finished.2019-09-26
-
Automatic pallet changer
The pallet system on the machine reduces unproductive time during machining. Machining can be carried out on one pallet, while the others can be used for preparation (seating and clamping of work-pieces etc.) The pallet system consists of two, or more pallets.
2019-09-17
-
APC dual pallets
A heavy duty 180° hydraulic rack & pinion driven indexing pallet changer, fitted with dual pallet carrier stations and aligned to an NC Rotary Table. Work table is rotated by a dual lead worm gear dirven via a servo motor and fitted with auxilary shot pins for pallet registration and stability. Heavy duty table clamping ensures rigidity and the accommodation of high machining loads. Self-Contained Exchanger, Rotary Table and Pallets "matched" for easy installation
2019-09-09
-
Types of CNC machining
Manufacturers worldwide are always looking for the most reliable work-holding devices on the market to accommodate their indexing and rotating needs. For more than 30 years, Ganro (Golden Sun) has been providing the world with a wide range of products to meet any manufacturing needs. To meet those needs, a manufacturer must know which table is the right choice and understand the proper use and capabilities of the different styles of equipment.
2019-06-24
